Air purification engineering refers to the removal of small particles, harmful air, bacteria and other pollutants in the air within a certain space, and the indoor temperature, cleanliness, pressure, air velocity and airflow distribution, noise, vibration and lighting, Projects where static electricity is controlled within a certain range of requirements. The room designed by the purification project is very special. No matter how the outside air conditions change, the room still maintains the originally set cleanliness, temperature, humidity, and pressure. Air purification engineering can be divided into turbulent flow clean room and laminar flow clean room according to the principle; according to application, it can be divided into industrial purification engineering and biological purification engineering. The air purification project is a complete system, and there are related instructions in the clean room design and acceptance specifications. Air purification projects generally include clean room building decoration system, purification air conditioning system, water system, electric system, air system, etc. The air purification project is to control the temperature, humidity, illuminance, cleanliness, and static electricity phenomenon in the clean room, so as to meet the specific process requirements. The air purification project has obvious effects in improving product quality. According to reports in foreign literature, products manufactured in semiconductors in Class 10000 and Class 100 clean rooms have passed the pressure test. They are tested in Class 100 clean rooms and outside atmospheric environments. For transistor coating and diffusion, the performance distribution of products in a class 100 clean room is concentrated, and the peak appears in the place of higher performance. The performance of the product in the atmosphere is extremely dispersed and the performance is extremely unstable. It can be seen that (1) whether there is air purification or not, the product yield is very different. (2) In order to improve product quality, not only the environment in which the product is produced needs to be clean, but the production of its key raw materials and ingredients should also be carried out in a clean environment. Nothing can be absolute, nor can the role of air cleaning technology be absolute, nor can the effect of improving product quality be attributed to it. According to the analysis of foreign materials, for the semiconductor component sector, for example, the role of air cleaning technology in improving product quality accounts for about 20% of the entire production, while the automation of the production process accounts for 60%, and other factors account for 20%. Of course, after the problem of the production process has been solved, air purification is the main contradiction. For example, very large-scale integrated circuits can hardly be produced without a clean environment. Industries and sectors that require air purifi...
What is a purification project? There are many names for clean room projects in China. Some people like purification projects, and some people like purification projects. In fact, the meaning of both is the same. The purification project is also known as the Cleanroom project. Used in clean room engineering, purification engineering is used as a method to avoid copyright infringement, so it is also known as clean room design. Purification projects can also be called clean workshops, clean rooms, clean rooms, sterile rooms, etc., but they are generally called purification projects. The purification project is to eliminate particles, harmful air, bacteria and other pollutants in the air within a certain space, and control the indoor temperature, cleanliness, pressure, air velocity and air distribution, noise, vibration, lighting, and static electricity within a certain range. Engineering disciplines within the scope of demand. The room specially designed by the purification project has the ability to maintain the cleanliness, temperature, humidity and pressure of the originally set requirements regardless of the changes in the external air conditions. Then, let me introduce the composition of the purification project. The purification project consists of six systems: clean room ceiling system, air conditioning system, clean room partition wall, floor, and lighting fixtures. 1) Ceiling system: Including suspenders, beams, ceiling lattice beams, the materials are generally: color steel plate and dust-free board 2) Air conditioning system: including the host, air duct, filter system, FFU, etc. 3) Partition wall panels: including windows and doors, the material is color steel plate, but there are many kinds of color steel plate sandwiches. 4) Floor: Raised floor or anti-static PVC floor or epoxy resin floor. 5）Lighting appliances: use dust-free special lamps. What is the purification project? What is the classification of purification engineering? Purification projects are mainly divided into three categories: turbulent flow purification projects, composite purification projects and laminar flow purification projects. 1. Turbulent flow purification project The air enters the clean room from the air-conditioning box through the air duct and the air filter in the clean room, and passes through the partition wall panels or raised floor on both sides of the clean room. 2. Compound purification project The compound type is to conform or use the turbulent flow type and the laminar flow type together, which can provide local ultra-clean air. 3. Laminar flow purification project The laminar air flow moves into a uniform straight line, and the filter with 100% coverage of the empty area enters the room, and the air is returned by the raised floor or partition walls on both sides. This model is tried for use in environments where the clean room level needs to be set higher. Generally, the clean room level is CLass1~100
Now in many industrial occasions, air purification filter is one of the indispensable facilities, especially in the environment with high hygiene requirements such as hospitals. The application of air purification technology in medicine, in particular, creates a highly clean space for surgical operations, reduces the infection rate of the operation, and increases the success rate. The following editor will take everyone to understand the air purification technology. Air purification technology, as the name implies, air cleanliness refers to the degree of cleanliness in the air. Air purification technology refers to the use of physical methods to effectively remove polluting particles and other pollution in the air, so that the air within the space can maintain a certain level Cleanliness. The value of cleanliness is usually measured by the concentration of dust. If the concentration of dust is high, the cleanliness is low. Among them, the cleanliness in the clean operating room cannot be lower than 100,000; Air purification technology is usually classified into turbulent flow, horizontal laminar flow, and vertical laminar flow. At present, the most widely used operating room is the vertical laminar flow. The following is an introduction to what kind of operations different levels of clean operating rooms are suitable for: Class I special clean operating room can usually be used for joint replacement surgery, organ transplant surgery, brain surgery, surgery, ophthalmology and other operations; Class II standard clean operating room can be used in thoracic surgery, surgery, urology, orthopedics and other operations; Class III general clean surgery is generally used in general surgery, obstetrics and gynecology and other operations; The Ⅳ-grade standard clean operating room is suitable for anorectal surgery and other operations. Professional in the clean room industry for decades, welcome to inquire about clean room ceiling system, clean room doors and windows, clean room equipment, etc.
Clean room refers to the removal of particles, harmful air, bacteria and other pollutants in the air within a certain space, and the control of indoor temperature, cleanliness, indoor pressure, air velocity and air distribution, noise, vibration, lighting, and static electricity In a certain range of needs, and given a specially designed room. That is to say, no matter how the external air conditions change, the room can maintain the original set requirements of cleanliness, temperature, humidity, and pressure. The main function of the clean room is to control the cleanliness, temperature and humidity of the atmosphere that the products (such as silicon chips, etc.) contact, so that the products can be produced and manufactured in a good environmental space. This space is called a clean room. One. Indicators of clean room. 1. The air supply in the clean room is sufficient to dilute or eliminate the pollution generated in the room. 2. The air in the clean room flows from the clean area to the area with poor cleanliness. The flow of contaminated air reaches the lowest level, and the air flows in the correct direction at the door and in the indoor building. 3. The air supply in the clean room will not significantly increase indoor pollution. 4. The movement state of the indoor air can ensure that there is no high concentration gathering area in the secret room. Two.Clean room testing. 1. Air supply and exhaust air volume: If it is a turbulent clean room, the air supply and exhaust air volume must be measured. If it is a one-way flow clean room, the wind speed must be measured. 2. Airflow control between each zone: In order to prove that the airflow movement direction between each zone is correct, that is, it flows from the clean area to the area with poor cleanliness, it is necessary to check: (1) The pressure difference in each section is correct; (2) The direction of air movement at the doorway or openings on the wall, floor, etc. is correct, that is, it flows from the clean area to the area with poor cleanliness. 3. Filter leak detection: The high-efficiency filter and its frame should be inspected to ensure that suspended pollutants will not pass through: (1) Damaged filter; (2) The gap between the filter and its outer frame; (3) Other parts of the filter device invade the room. 4. Isolation leak detection: This test is to prove that suspended pollutants do not penetrate the building materials into the clean room. 5. Indoor airflow control: The type of airflow control test depends on the airflow mode of the clean room-turbulent flow or unidirectional flow. If the air flow in the clean room is turbulent, it must be verified that there is no area with insufficient air flow in the room. If it is a one-way flow clean room, it must be verified that the wind speed and direction of the entire room meet the design requirements. 6. Suspended particle concentration and microbial concentration: If the above tests meet the requirements, the particle concent...
Clean technology, also known as production environment and pollution control technology, is a comprehensive emerging science and technology developed with high technology in recent years. Clean technology usually includes: air purification technology, air conditioning technology, water purification technology, gas purification technology, micro-magazine control technology, clean environment detection technology and related environmental control technology. Purification engineering technology is widely used in high-tech industrial fields such as electronics, nuclear, aerospace, bioengineering, pharmaceuticals, precision machinery, chemicals, food, automobile manufacturing, and modern science. With the improvement of people’s living standards in our country, people have put forward higher and higher requirements for the living environment and quality of life. High-purity water prepared by water purification equipment has been generally welcomed by people. Purification engineering technology has begun to enter thousands of households and enter people’s modern life. . Compared with advanced foreign countries, my country's clean technology and equipment are obviously far behind. The HEPA filter that my country only began to produce in 1965 is fifteen years older than foreign countries. The light scattering dust particle counter that started production in 1975 was twenty years later than abroad. 0.1 micron clean technology and equipment have become mature technologies in advanced countries in the world, while my country has just started. In terms of the scale and technical level of clean room construction, the gap between my country and advanced countries is even greater. Japan’s Shimizu Construction Company. The clean room area under contract from 1982 to 1987 reached 718 thousand square meters, while the total area of clean room under contract in my country is less than 100,000 square meters. Great development. The total area of clean rooms under contract in 1993 was close to 150,000 square meters. The scale of clean room construction in the United States is even larger. In 1998, statistics reached 1.885 million square meters. In terms of the level of clean engineering technology, in the late 1980s, a large number of ultra-clean rooms of 0.1 micron level had been built abroad. In 1987, Sanyo Niigata Factory in Japan built a tenth level clean workshop of 3000 square meters, and NIT logs built four 1000 square meters. Meters control 0.1 micron dust in a thousand-level workshop, and the number of air changes is as high as 300 times per minute. The new US TSMCS plant in Taiwan has built a fourth-generation ducted clean room with a total area of 10,000 square meters. The 0, 1 micron grade 10 clean room used in my country mainly depends on imports from abroad. Because the cost of a clean room with a high level of cleanliness is very expensive, the cost per square meter of a 0.1 micron class 10 clean room is as high as 10,000 US dollars. Clean workshops occ...
China's clean technology started in the early 1960s. In 1964, a sodium flame test bench for high efficiency filters was built. In 1965, the Air Conditioning Research Institute of the Chinese Academy of Building Research developed GS series high efficiency air filters with blue asbestos fiber filter paper (for later use) and GB series high efficiency air filters with ultra-fine glass fiber filter paper. In 1973, China’s first dust particle counter model J-73 (measuring range 0.3~10μm) and monodisperse polystyrene latex standard particles (PSL) for calibration of particle counters were successfully developed. ED-STD-209A standard 100,000 to 100 clean workshop design and construction. From the late 1970s to the late 1980s, it was the stage of maturity and development of China's clean technology. In 1979, the Air Conditioning Institute of CABR organized the compilation and publication of "Technical Measures for Air Cleaning", which was China's first normative document on clean technology. n June 1982, the Clean Technology Branch of the Chinese Institute of Electronics (CCCS) was established, and the professional magazine "Clean and Air Conditioning Technology" was published, which played a significant role in promoting the progress of clean room technology and international exchanges. In 1984, the national standard GBJ73-84 "Code for Design of Clean Workshops" was issued, and now the latest version is GB 50073-2013 "Code for Design of Clean Workshops". Later, according to the needs of the industry, various clean technical specifications and standards of electronics, medical and health, food, and microbiological safety have been published. After the 1990s, China's clean technology has gradually integrated with the international standards. From the theoretical research of clean technology to the research and production of clean products, and the detection and control of clean environment, my country has gradually reached the level of developed countries in the world. In recent years, most areas of our country have been more and more severely affected by smog. The concept of home purification has begun to spread. Cleanliness has gradually penetrated into everyone’s thoughts and lives. Related new technologies and products continue to emerge, which will become a new industry in the clean industry Opportunities and development points. Welcome to inquiry sliding doors for clean room、clean room profiles、hpl partition wall and clean room partition panels etc.
