Knowledge about clean room pass box

Jan 30,2021
The clean transfer window is a kind of auxiliary equipment for the clean room. It is mainly used to transfer small items between the clean area and the clean area, and between the clean area and the non-clean area to reduce the number of door openings in the clean room and make the clean room clean area. The pollution is reduced to a minimum.
Features of clean transfer window:   

1. The clean room pass box body and inner liner are made of stainless steel, smooth and dust-free. It adopts a new type of ozone-free ultraviolet lamp with high intensity and long life. The overall appearance is beautiful, generous and corrosion resistant. The work surface and box body are made of sandwich panel, which is smooth and clean.

2. It is flexible to open and durable. The two doors are equipped with mechanical interlocking or electronic interlocking devices, so that the doors on both sides cannot be opened at the same time. 

3. The window is 5mm transparent tempered glass;   
4. The two electronic interlocking transmission window boxes are equipped with door opening signal indicator lights to know the opening status of the opposite clean room window and door.  
5. A special sealing strip is installed on the transfer window to ensure air tightness. The clean transfer window is divided into mechanical interlock and electronic interlock.

6. The overall design is rigorous, the structure layout is reasonable, and the use is convenient. According to different purposes, indoor lamps and germicidal lamps can be added.

7. clean room pass box of various specifications and models can be processed according to user requirements.

Installation and use of clean transfer window
1. Installation:   
The clean transfer window should be installed in the civil wall of the clean outdoor or in the composite sandwich color steel plate supporting the clean room. The device should be placed smoothly. It should be equipped with a special power supply, and the operation can be checked after the power supply is connected as required. After installation, clean up the site, use a vacuum cleaner or use long-fiber fabric to wipe all parts.  
2. Use:   

The sterilization lamp should be turned on 20 minutes before use.
