Overview:
HPL sandwich panel utilizes high-pressure laminate (HPL) as the surface layer, bonded to an insulated core (e.g., PIR or rock wool). Designed for cleanroom and industrial applications, it offers chemical resistance, scratch-proof durability, and easy disinfection. Available in fire-rated and non-fire-rated variants, it ensures hygienic, low-maintenance surfaces while providing thermal insulation and sound dampening, widely used in laboratories, hospitals, and food processing facilities.
Product Origin:
ChinaShipping Port:
ShanghaiLead Time：
25
Advanced modular wall solutions specialized for cleanrooms, workshops, and high-tech factories. Engineered to EN438 standards.
Get Quick Quote ✉The High-pressure laminate (HPL) 4 mm thick is a solid compound consisting of over 40 layers of paper impregnated with melamine and phenolic resins. The sheet of HPL, measuring 1300x3050 mm, has a transparent finishing layer on both external sides that protects the decorative layer below. The central layer is composed of Kraft papers pressed to 9 MPa at 150 °c. A protective PVC coating protects the panel during the production, transportation and installation phases. We chose to use HPL-grade products only, in accordance with standard EN438.
| Feature | Wonclean HPL System | Ordinary Steel Panels |
|---|---|---|
| Surface Hardness | Extreme (EN438 Grade) | Medium |
| Chemical Resistance | Excellent (Acid & Alkali) | General |
| Moisture Resistance | 100% Water-resistant | Prone to oxidation |
| Impact Resistance | High (Solid compound) | Moderate |
| Name | HPL wall system |
| Item | HPL sandwich panel |
| Panel Thickness | 50mm / 75mm / 100mm |
| Panel Width | 900mm to 1200mm (Customized) |
| HPL Face Thickness | 4mm / 4.5mm (FA04 Type) |
| Core Material | Inorganic non-combustible core |
| Dimensions | 1200*2400mm / 1200*3000mm |
Prefabricated wall structure: Details processing for integrated construction technology.
Overview: Medical clean panel is a specialized modular component engineered for healthcare and pharmaceutical cleanrooms. Featuring anti-bacterial HPL or coated metal surfaces with mineral wool or PIR cores, it prevents microbial growth and particle shedding. Classified by fire resistance and cleanability grades, it integrates seamless joints and smooth finishes to support sterile environments, ensuring compliance with GMP and ISO standards while enabling rapid installation and long-term hygiene maintenance.
Overview: Cleanroom injection panel is a specialized modular panel designed for utility and service integration in controlled environments. It embeds pre-installed electrical conduits, data ports, or gas lines within insulated wall structures, allowing seamless connection of lab equipment. By centralizing service distribution, it maintains cleanliness standards while improving accessibility, commonly used in pharmaceutical fill lines and electronics assembly cleanrooms.
Overview: Fiberglass panel is a lightweight, durable panel composed of fiberglass-reinforced material, often with resin or composite facing. Known for its excellent chemical resistance, thermal stability, and non-corrosive properties, it is used in corrosive or humid environments. Common in cleanrooms, chemical labs, and industrial settings, it provides smooth, easy-to-clean surfaces and consistent performance under varied conditions, offering a cost-effective alternative to metal or laminate panels.
Overview: Cleanroom partition system is an integrated modular solution composed of standardized panels, sealing profiles, and structural supports. Designed to create certified cleanroom spaces, it provides airtight barriers, smooth cleanable surfaces, and thermal insulation. With classifications for different cleanliness levels (ISO Class 5-8), it enables flexible space design for industries requiring controlled contamination, such as semiconductor production and biomedical manufacturing.
Overview: Cleanroom demountable partition wall is a reusable, modular wall system engineered for controlled environment flexibility. Featuring insulated panels (e.g., PIR, rock wool) with airtight seals, it enables rapid reconfiguration of cleanroom layouts without major construction. Ideal for temporary or expandable facilities, it supports ISO classification compliance while reducing renovation time and cost, commonly used in pharmaceutical pilot labs and R&D environments.
Overview: Sandwich panels are essential in cleanroom construction for creating and maintaining contamination-controlled environments. Their seamless surfaces, tight joints, and smooth finishes prevent particle accumulation and allow easy disinfection, while the insulated core helps regulate temperature and humidity. These panels are widely used in pharmaceuticals, electronics, food processing, healthcare, and other industries requiring strict environmental control.
Overview: Ventilation sandwich panel is a specially designed panel that integrates air channels within the insulation core, enabling seamless air distribution without additional external ductwork. It supports efficient airflow management for HVAC systems in cleanrooms, with metal or composite surfaces ensuring airtight, particle-free pathways. This design reduces system complexity, saves overhead space, and maintains consistent air quality, commonly used in controlled environments requiring integrated ventilation solutions.
Overview: Soundproof panel is an acoustic insulation panel designed to control noise transmission in industrial and commercial settings. Featuring high-density cores (e.g., mineral wool, fiberglass) and sealed, layered construction, it effectively dampens airborne and impact noise. Available in varying thicknesses and finishes, it supports sound-sensitive environments such as laboratories, studios, and production areas, improving acoustic comfort while maintaining thermal and structural performance.
Overview: Cleanroom FFU Ceiling Grid System incorporates Fan Filter Units (FFUs) into a modular grid structure, providing localized vertical laminar airflow. It enables flexible cleanroom classification control, energy-efficient air recirculation, and simplified filter maintenance. Widely used in semiconductor and biotechnology facilities, it ensures precise particle filtration and adaptable clean zone configurations.
Wonclean specialized in design,manufacture and construction of Modular clean room-video for a wide variety of applications.More info about Modular Cleanroom,you can visit wonclean.com directly. { "@context": "http://schema.org", "@type": "Article", "headline": "Modular Clean Room-video Design,Modular Clean Room-video Manufacturers", "author": { "@type": "Person", "url": "https://www.wonclean.com/", "name": "Wonclean" }, "image": "https://www.wonclean.com/uploadfile/202312/25/c64a2135f40633ec107f44aacea918ed_thumb.jpg", "articleBody": "Wonclean specialized in design,manufacture and construction of Modular clean room-video for a wide variety of applications. More info about Modular Cleanroom,you can visit wonclean.com directly." }
Overview: Clean laminar flow hood provides a sterile, unidirectional airflow workspace to prevent contamination of samples or products. Available in vertical and horizontal airflow configurations, it ensures ISO Class 5 (or higher) air cleanliness, protects personnel and processes, and supports critical operations in pharmaceuticals, electronics, and microbiology laboratories.
Overview: Pass box is a kind of auxiliary equipment for clean room. It is mainly used for the transfer of small items between clean area to another clean area, between clean area and non-clean area, to reduce the number of times the clean room is opened and pollute the clean room. Reduce to a minimum. The transfer window is made of stainless steel and is smooth and smooth. The double doors are interlocked to each other to effectively prevent cross-contamination. They are equipped with electronic or mechanical interlocking devices and equipped with ultraviolet germicidal lamps.
