Operating room laminar flow air supply ceiling-clean air supply ceiling
Operating room laminar flow air supply ceiling-clean air supply ceiling is the clean operating room, the purifying air supply end of the laminar flow ward, it has the functions of high efficiency filtration, flow sharing and air flow compensation. The rationality of the structure of the laminar flow purifying air supply ceiling directly affects the air supply effect and purification level of the operating room. KLCFILTER laminar flow air supply ceiling is the crystallization of the experience and practice of operating room air supply terminal in the past ten years. This type of terminal has been used in nearly a thousand operating rooms. Its superior performance and unique double-layer DPP flow-sharing network energy The airflow is evenly sent to the working area, and the central airflow compensation device can effectively eliminate the influence of updraft caused by the heating of personnel and equipment on the laminar flow.
Operating room laminar flow air supply ceiling-clean air supply ceiling Working principle:
The air supply ceiling consists of a high-efficiency air disinfection and filtration system, a fan power system, a noise reduction system, and an operation control system. When working, the fan inhales ambient air, filters it into clean and sterile air through the air purification and disinfection system, and then delivers clean air to the hospital bed area in the cover in a laminar flow, while maintaining a positive pressure in the cover to prevent dust in the external space Particles and microorganisms enter the hood.
With the rapid development of modern medical science and technology, surgical technology has higher and higher requirements for the clean conditions of the operating room. The 100-level laminar flow operating room is currently the most ideal. However, how to effectively manage the number of air colonies in the laminar flow operating room to meet the air environmental hygiene standards issued by the Ministry of Health, and to meet the clean operating room grade standards, and to reduce it to the minimum. There are few domestic search documents and data. A new topic worth discussing in the management of clean operating room. Laminar flow air supply ceiling adopts air cleaning technology to control microbial pollution in different degrees to achieve the requirements of air cleanliness in the controlled space environment and suitable for various operations; and provide suitable temperature and humidity to create a clean and comfortable operating space surroundings.
Features of laminar flow ceiling:
Hundred-level air supply ceiling-Dust-free purification ceiling manufacturer's new second-generation German FFA technology laminar flow purification ceiling, laminar flow ceiling is the purifying air supply end of clean operating room and laminar flow ward, it has both high-efficiency filtration, uniform flow and air flow Compensation effect. The rationality of the structure of the laminar flow ceiling directly affects the air supply effect and purification level of the operating room. Vertical air supply mode, special stainless steel laminar flow air supply ceiling for the operating room: Laminar flow air supply ceilings are developed with reference to international and domestic specifications and technologies. More than ten years of experience in actual hospital use, advanced and reasonable structure, divided into I, II, III operating rooms, the box body is cold plate sprayed, the lower frame is all stainless steel, beautiful and durable. The clean air supply ceiling device is based on the leading leakage barrier technology at home and abroad. The use of this equipment can reasonably distribute the air flow in the clean room and effectively ensure the indoor cleanliness (air supply surface level 100).
Operating room laminar flow air supply ceiling-clean air supply ceiling technical parameters:
Model parameter A-Ⅰ A-Ⅱ B-Ⅲ
Filtration efficiency 99.99%
Wind speed (m/s) 0.45 0.3 0.23
Air supply surface size (mm) 2600×2400 2600×1800 2600×1400
Filter type with partition or combination
Use occasions Class I special clean operating room Class II standard clean operating room Class III general clean operating room
Advantages of our operating room dedicated laminar flow air supply ceiling:
The use of stainless steel (electrolytic steel plate) laminar flow air supply ceilings are developed with reference to international and domestic specifications and technologies. The structure is advanced and reasonable and has the following characteristics:
A Product specifications: Class I 2600*2400, Class II 2600*1800, III2600*1400;
B. Air supply form: laminar air supply ceiling is divided into two types: high efficiency filter full air supply and high efficiency filter side air supply;
C Air flow status: uniform air flow in the lower part of the air supply ceiling, air flow rate ≧95%, which meets the relevant parameter requirements of national testing;
D Flow-sharing mode: combination of multiple mesh plates, uniform wind, electrostatic powder spraying, the same color as the top surface of the wall, good surface effect;
E Factory manufactured, standard connectors are used for splicing and assembly on site, convenient and simple installation, and the quality of equipment installation is guaranteed;
F Maintenance operation: National standard filter, replacement is quick, convenient and easy to maintain.
Welcome to inquiry clean room false ceiling、clean room wall panels and clean room ceiling etc.
