HPL panel

Overview:

HPL wall system is composed of HPL sheet, which is a high-tech green and environmentally-friendly decorative sheet. The surface is made of a special material and covered on the color layer.


  • Payment:

    T/T
  • Product Origin:

    China
  • Shipping Port:

    Shanghai
  • Lead Time:

    25
  • Product Details

Introduction detail:

The High-pressure laminate (HPL) 4 mm thick is a solid compound consisting of over 40 layers of paper impregnated with melamine and phenolic resins. The sheet of HPL, measuring 1300x3050 mm, has a transparent finishing (1) layer on both external sides that protects the decorative layer below. The central layer, dark brown (3), is composed of a series of Kraft papers impregnated with phenolic resins, pressed to 9 MPa at 150 °c. A protective PVC coating protects the panel during the production, transportation and installation phases. We chose to use HPL-grade products only, in accordance with standard EN438.

Detail picture:





Products specification



Name

HPL wall system

Item

HPL sandwich panel

Panel Thickness

50mm/75mm/100mm

Wall/Roof Panel Length

Customized

Wall/Roof Panel Width

900mm/950mm/1000mm/1100mm/1200mm

HPL Thickness

4mm

Application

Cleanroom, Workshop, Factory

Color

Customized





Products  feature

1. Melamine impregnated surface paper
2. Decorative colored paper
3. Inorganic non-combustible core material
4. Decorative colored paper
5. Melamine impregnated surface paper

Thickness

4.5mm

Type

FA04

Dimensions

1200*2400mm,1200*3000mm

Match texture

60sides (suede)



Products advantage

1.The material used for  HPL panel for cleanroom  is high-tech green decorative profile.

2.Excellent impact resistance, moisture resistance, excellent surface wear resistance and scratch resistance.

3.At the same time, it has good advantages such as acid and alkali resistance, weather resistance, easy cleaning and good fire resistance.

4.Achieve integrated processing and construction technology, economical.
